500 type disc wood crusher

500 type disc wood crusher

The 500 disc wood pulverizer is a small to medium-sized wood processing equipment. It adopts a disc crushing structure and is specially designed for processing wood materials such as tree branches, logs, and square timber. The crushing particle size is adjustable from 1 to 20 mm, and it is suitable for landscaping, small-scale wood recycling, and biomass fuel preparation.

model numberModel 500
Diameter of cutter plate500 mm
Number of blades4 pcs
Blade Size120*70mm
Inlet size170*180 mm
Maximum feed size150 mm
power18.5kw/32HP
Output Size1-20mm(Depends on the mesh size)
production capacity1.5 t/h

The 500 disc wood pulverizer is a small to medium-sized wood processing equipment. It adopts a disc crushing structure and is specially designed for processing wood materials such as tree branches, logs, and square timber. The crushing particle size is adjustable from 1 to 20 mm, and it is suitable for landscaping, small-scale wood recycling, and biomass fuel preparation.

Core Advantages:
Powerful Crushing: Driven by an 18.5kW motor or diesel engine, combined with high-hardness alloy discs, it effortlessly processes wood with a diameter of ≤15cm.
Energy-Efficient and Eco-Friendly: Optimized power system design reduces energy consumption by 20% and minimizes noise levels.
Mobile and Flexible: The compact chassis can be paired with a diesel-powered mobile chassis, offering strong adaptability to various sites.
Durable and Cost-Effective: The blades can be repeatedly sharpened for reuse, reducing maintenance costs by 50%.

With a processing capacity of 1.5 tons per hour and energy consumption 30% lower than comparable products, the 500 model is an ideal choice for small-scale wood processing enterprises, supporting resource recycling and green production.
