tree root crusher

Tree Root Crusher

Equipment for producing 20-80 mm wood chips

0-2200MM

Feed size

110-160KW

Power

5-30T/H

Capacity

Get detailed specifications in PDF format.

Download PDF

Overview

A tree root crusher is a piece of coarse crushing equipment used in the initial stage of wood processing. Designed specifically to handle materials such as tree roots, large logs, branches, crop stalks, and waste wood, it produces wood chips ranging from 20 to 80 millimeters in size and is widely used in sectors such as biomass energy, forestry, and waste wood recycling.

High Efficiency

High crushing capacity, stable performance

Wide Application

Suitable for a wide range of raw materials and industries.

Durable Design

High-quality components ensure a long service life.

Easy Maintenance

Simple structure, easy to operate.

Key Specifications

Model	power (kw)	Feed size（mm）	Discharge size (mm)	capacity (t/h)
2600	110kw	≤ ø1600	20-80	5-10
3200	132kw	≤ ø2200	20-80	10-20
3600	160kw	≤ ø2200	20-80	20-30

Accessories

Blade Roller

High-strength alloy blade, providing uniform cutting and a long service life.

Hammer Roller

Suitable for shredding branches, pallets, and various wood materials.

Applications

Biomass Power Plant

Wood Pellet Plant

Plywood Factory

Paper Mill

Landscaping & Mulch

Need Help Choosing The Right Machine?

To contact our team, please click “Contact Us”.

Specifications

Detailed technical data and performance of our Comprehensive Wood Crushers.

MT-2600
Host Power	110KW
Diesel Engine Specifications	320HP
Feed Size	≤ ø1600mm
Output Size	20-80mm（Adjustable）
Hammer Head Types	Blade-type/Hammer-type (optional)
Number of Blades	4 pcs
Number of hammers	Customizable
Feed Inlet Diameter	2600mm
Discharge Conveyor Dimensions	12000mm
capacity	5-10 T/H
Equipment Weight	11000kg
Equipment dimensions（LWH）	550023003200mm

MT-3200
Host Power	132KW
Diesel Engine Specifications	340HP
Feed Size	≤ ø2200mm
Output Size	20-80mm（Adjustable）
Hammer Head Types	Blade-type/Hammer-type (optional)
Number of Blades	5 pcs（Optional）
Number of hammers	Customizable
Feed Inlet Diameter	3200mm
Discharge Conveyor Dimensions	12000mm
capacity	10-20 T/H
Equipment Weight	12000kg
Equipment dimensions（LWH）	550027003200mm

MT-3600
Host Power	160KW
Diesel Engine Specifications	460HP
Feed Size	≤ ø2200mm
Output Size	20-80mm（Adjustable）
Hammer Head Types	Blade-type/Hammer-type (optional)
Number of Blades	7 pcs（Optional）
Number of hammers	Customizable
Feed Inlet Diameter	3600mm
Discharge Conveyor Dimensions	12000mm
capacity	20-30 T/H
Equipment Weight	13000kg
Equipment dimensions（LWH）	650028003200mm

The above specifications are for reference only and are subject to change without prior notice.

Need Help?

Our team is ready to help you choose the right model for your needs.

Download Specification

Get detailed specifications in PDF format.

DOWNLOAD PDF

Need Help Choosing The Right Machine?

Please click “Contact Us” or fill out the form.

Product Video

Watch our Comprehensive Wood Crusher in action and see how it works.

Need more information?

Contact our team to get more videos or a customized solution.

Gallery

Explore our Comprehensive Wood Crusher from different angles and details.

High Quality Images

All images are taken from real machines. Click to view larger high-resolution photos.

Download Images

You can download product images for your presentations and promotions.

DOWNLOAD ALL IMAGES

Share This Gallery

Share these images with your colleagues or partners.

Need more photos or information?

Contact our team to get more technical images or a customized solution.

Product Options

Customize your Comprehensive Wood Crusher to match your working conditions and production needs.

1.Power Options

Choose the power source that suits your operation.

Electric Motor

Stable performance, low noise suitable for fixed operation.

Diesel Engine

High power, portable and suitable for remote areas.

2.Mobility Options

Choose the mobility solution for your operation.

Fixed Type

Stable installation, suitable for fixed site.

Mobile Type

Self-propelled via tracks or towed via wheels for convenient transport.

3.Blade Type Options

Choose the blade type based on your raw material.

Blade Type

High-precision cutting; suitable for processing logs and branches.

Hammer Type

High impact resistance, suitable for waste wood with nails or impurities.

4.Discharge Size Options

Adjustable output size to match your final use.

30–50 mm

Medium chips

40–80 mm

Large chips

5.Additional Options

More configurations to improve your production.

Magnetic Separator

Remove metal impurities.

Dust Removal System

Reduce dust, protect environment.

Need help choosing the right options?

Our experts are ready to help you customize the best solution for your needs.

Frequently Asked Questions

View FAQs about our comprehensive wood crusher.

Q1: What is a Tub Grinder (Disc Root Shredder), and why is it preferred for processing tree roots?

A:
A tub grinder features a massive top-loading rotating tub (disc hopper) that allows excavators or log loaders to easily drop bulky, irregularly shaped tree roots, whole tree trunks, and overgrown branches into the tub without complex pre-cutting. The rotating motion feeds material continuously into the bottom rotor drum, making it the most efficient solution for clearing land waste, stumps, and orchard debris.

Q2: How do I choose between a Blade Rotor and a Hammer Rotor for a Tub Grinder?

A:
Blade Rotor: Ideal for clean, organic woods such as fresh logs, large tree roots without stone/soil contamination, branches, and crop straw. It produces uniform wood chips suitable for pulp, biomass fuel, or mulch.
Hammer Rotor: Ideal for waste wood containing metal or dirt, such as demolition timber, dirty tree stumps with soil/rocks, waste furniture, and wooden pallets with nails. The heavy-duty alloy hammers smash wood through high impact while resisting severe wear from hard debris.

Q3: What is the difference between the Tub Diameter and the Effective Processing Diameter?

A:
The tub diameter refers to the top opening width of the rotating hopper, while the effective processing size is the maximum timber width/diameter that the bottom rotor throat can directly grind:
2600mm Tub: Effective processing size up to 1600mm.
3200mm Tub: Effective processing size up to 2200mm.
3600mm Tub: Effective processing size up to 2200mm.
Selecting the tub size depends on your loader bucket size and how wide the raw tree stumps/logs are before loading.

Q4: Can this tub grinder handle wooden pallets with iron nails and contaminated tree roots with dirt?

A:
Yes. When configured with a Hammer Rotor, the machine easily handles nailed pallets and waste roots with soil. Heavy alloy hammers break down timber without cracking blade edges. We highly recommend installing an optional magnetic separator conveyor at the discharge belt to automatically collect nails and metal debris.

Q5: What power source options are available, Electric Motor or Diesel Engine?

A:
Both power options are available depending on your site requirements:
Electric Motor: Ideal for stationary recycling yards with stable electric grids, offering lower power costs and less daily maintenance.
Diesel Engine (Cummins / Weichai / Caterpillar, etc.): Autonomous power designed for remote forest clearing, field operations, or landfill sites where high-voltage electricity is unavailable.

Q6: What is the difference between Stationary, Towable Wheel-Mounted, and Tracked Mobile versions?

A:
Stationary: Fixed base frame setup, cost-effective for dedicated indoor/outdoor recycling plants.
Wheel-Mounted Towable: Mounted on a heavy-duty trailer chassis, easily towed by trucks or tractors between work sites.
Tracked Self-Propelled Mobile: Features hydraulic crawlers and wireless remote control. It can walk autonomously across rugged forest terrain, muddy land, or steep hills directly to the pile of tree stumps.

Q7: How does the rotating tub prevent material bridging or jams during feeding?

A:
The rotating tub features a smart forward/reverse drive system with speed adjustment. When the lower rotor encounters high load, the tub automatically slows down or temporarily reverses rotation to redistribute the material, ensuring smooth, continuous feeding without manual intervention.

Q8: What safety features are designed to prevent flying debris during top loading?

A:
The disc-type tree root shredder is equipped with heavy-duty metal deflector plates along its top edge, features a deep-trough design, and is engineered with an optimal trough angle to prevent debris from spilling out. In addition, operators can control both the machine and the feed loader simultaneously from a safe distance using a fully functional wireless remote control system.

Q9: Can the output material size be adjusted?

A:
Yes. Output particle size is controlled by interchangeable bottom discharge screens (mesh size options range from 30mm to 100mm+), tub rotation speed, and hammer/blade tip velocity. Screens can be quickly swapped to match downstream fuel, boiler, or composting requirements.

Q10: What are the primary wear parts, and how are they maintained?

A:
The primary wear parts include the hammers/knives, anvil (counter blade), and bottom screen plates.
Hammers: Tipped with tungsten carbide wear coatings for high impact resistance (typical lifespan: 400–800+ hours).
Maintenance: Our tub grinder features a hydraulic tub-opening mechanism, swinging the upper tub open in minutes for unobstructed, safe access to the rotor and screens.
