（diesel）tree root crusher
The diesel-powered mobile stump grinder operates without site restrictions, specializing in processing large-sized tree stumps, logs, and other oversized materials.
0-2200MM
Feed size(Log size）
320-460HP
power
5-30T/H
Production capacity
Products Advantages
The diesel-powered mobile stump crusher is a powerful machine that thoroughly pulverizes tough tree roots into wood chips on-site, making it an effective tool for forest restoration and landscaping. Equipped with a mobile chassis and a diesel engine, it can traverse complex terrain, directly crushing difficult tree roots with high efficiency and environmental protection.
Diesel-Powered Mobile Root Crusher
The diesel mobile stump crusher is a specialized machine for processing tree roots. Leveraging high-power diesel power and a high-speed cutter drum, it can completely crush tough tree roots into wood chips on-site. Its mobile chassis ensures excellent maneuverability and operational stability in complex field terrain, enabling efficient, environmentally friendly, and cost-effective one-stop processing from tree roots to wood chips.
Root Crusher Capacity Range
Different models of stump crushers have different production capacities. Mantor Machinery offers a range of capacities including 5-10t/h, 10-20t/h, and 20-30t/h to meet different production capacity requirements.
Tree Root Crusher Applicable Materials
The stump crusher is designed specifically for processing a variety of wood and plant-based materials. Its powerful crushing capacity is suitable for common forestry waste such as roots, stumps, and trunks, while also efficiently processing specialized materials such as palm trees, shrubs, bamboo, and coconut shells. Furthermore, it is widely used for crushing construction and recycled materials such as scrap wood, building formwork, wooden pallets, and furniture scraps, realizing resourceful waste recovery.
Advantages of the Root Crusher
The diesel mobile root crusher, with its own power and mobile chassis, demonstrates unparalleled flexibility. It can directly penetrate into complex sites such as woodlands and construction sites for on-site crushing, greatly saving raw material transportation costs and expanding the scope of operations. It is the best solution for achieving efficient on-site processing.
Working Principle
The diesel mobile stump crusher is powered by a high-powered diesel engine. Its transmission system drives a high-speed rotation of a cutter drum equipped with carbide cutters. During operation, tree roots and other raw materials are fed into the feed hopper. They are subjected to intense cutting, impact, and tearing by the cutter drum, rapidly crushing them into uniform wood chips. These chips are then conveyed by a discharge conveyor to a designated location or transfer vehicle. This machine combines a mobile chassis with crushing capabilities, enabling flexible and stable operation in a variety of complex sites, achieving efficient and environmentally friendly, one-stop processing from tree roots to wood chips.
Model And Technical Parameter
| Model | 2600 | 3200 | 3600 |
|---|---|---|---|
| power (HP) | 320HP | 340HP | 460HP |
| Inlet size | 2.6m | 3.2m | 3.6m |
| Effective processing size | 1.6m | 2.2m | 2.2m |
| Output Size (mm) | 30-50 | 30-50 | 30-50 |
| capacity (t/h) | 5-10 | 10-20 | 20-30 |
Note: The parameters in the table are for reference only. Products are subject to updates and changes. For the latest information, please contact us.
