（horizontal）Wood Powder Machine
The horizontal wood powder machine features a stable design, strong grinding capacity, and smooth operation, ideal for producing fine wood powder efficiently and continuously.
0-30MM
Feed size
22-55KW
power
0.1-0.8T/H
Production capacity
Products Advantages
The horizontal wood powder machine efficiently grinds wood materials into fine powder through high-speed rotation and strong impact force.
horizontal wood powder machine
The horizontal wood powder machine is specifically designed for the fine grinding of wood materials such as sawdust, wood chips, bamboo, and crop straw. Through the action of a high-speed rotating rotor and impact blades, it produces uniform wood powder.
Wood Powder Machine Production Capacity
Different models of wood powder machines offer multiple production capacity options. Manto Machinery provides the following capacity specifications: 0.1-0.3 tons per hour. Output varies depending on required fineness, with final yield determined by the desired particle size of the finished product.
Wood Powder Machine Applicable Raw Materials
The horizontal wood powder machine is suitable for processing various materials such as wood chips, sawdust, bamboo, coconut shells, tree bark, and crop stalks, efficiently converting them into fine wood powder for industrial use.
Advantages of wood powder machine
The horizontal wood powder machine offers high efficiency, stable performance, and low energy consumption. Its horizontal design ensures continuous feeding, uniform output, and easy maintenance, making it ideal for large-scale wood powder processing.
Working Principle
The horizontal wood powder machine operates by feeding raw materials into a high-speed rotating grinding chamber, where hammers and blades crush the wood through impact and shear force. The resulting fine powder is discharged through a screen with uniform particle size.
Model And Technical Parameter
| Model | 550 | 650 | 750 | 850 |
|---|---|---|---|---|
| Power（kw） | 22kw | 30kw | 37kw | 55kw |
| Feed size（mm） | 20-30 | 20-30 | 20-30 | 20-30 |
| Finished dimensions(mesh) | 30-200 | 30-200 | 30-200 | 30-200 |
| Capacity（kg/h） | 20-250 | 20-400 | 20-600 | 20-800 |
Note: The parameters in the table are for reference only. Products are subject to updates and changes. For the latest information, please contact us.
